FIFISH UK & Ireland - FIFISH E-GO accessories

FIFISH E-GO Accessories

The Q-IF (QYSEA Interface) enables FIFISH E-GO to attach a variety of optional accessories for various applications and multiple tasks.

You will also find E-GO spare accessories on this page.

inspection tools

Industrial remote controller

No need to use your phone or tablet, simply connect your ROV to the Q-iRC industrial remote controller. With it’s 7″ 1080p HD screen, multi-window display, multiple expansion ports and up to 8hrs use this is a must for serious users.

Further details on the Q-iRC can be found here

For use with FIFISH E-GO

2D Image sonar

Optional 2D Image Sonar modular for inspection under dark and turbid water environment.

For use with FIFISH E-GO

Q- Camera

The optional Q-Camera can be controlled in real time, and have real-time video transmission function. Multi-angle installation, more flexible underwater view angles. Freely switch between the main camera and the Q-Camera split screen display.

Q-Camera specifications

Camera
Sensor: 1/2.3″ SONY CMOS
Apture: f/2.5
Max video res: 4k UHD: 25/30 fps
Video format: MPEG4-AVC/H.264, HEVC/H.265
Effective pixels; 12MP
Stabilisation: EIS (Electrical Image Stabilisation)
ISO Range: 100 – 6400 in auto/manual
Photo format: JPEG, DNG
White balance: 2500-8000k, auto/manual
Storage: External pluggable micro SD, 64 – 512GB
Field of view: 166º

General
Depth rating: 150m
Operating temp: -10 to 60º

Installation Angle
0º; Front vision, 90º; Right side vision
180º; Back vision, 270º; Left side vision

LEDs
Brightness: 500 x 2 Lumens
Control APP: Be controlled by FIFISH APP

For use with FIFISH E-GO

SPORTS CAMERA MOunt

Optional rugged universal sports camera mounting bracket. Can be installed at the top of the unit to deliver simple and convenient method to shoot various angles.

For use with FIFISH E-GO

metal detector

The Qysea underwater metal detector is an instrument that detects the presence of metal nearby. Metal detectors are useful for finding metal inclusions hidden within objects, or metal objects buried underground.

For use with FIFISH E-GO

external lighting mount

Optional mounting bracket for additional external light.

For use with FIFISH E-GO

measurement

laser scaler

Accurately measure the sizes of underwater objects, pits, cracks, fish, and more with QYSEA’s high-precision laser.

For use with FIFISH E-GO

ar ruler

Utilise augmented reality technology (AR) with laser scaling technology to accurately measure the sizes of underwater objects with high precision and ease.

For use with FIFISH E-GO

distance meter

Measure and identify the distance between the ROV and target object underwater.

For use with FIFISH E-GO

Altimeter

Effectively determine, measure, and fix the height between the FIFISH ROV and seafloor, with real-time automatic adjustments.

For use with FIFISH E-GO

compass ruler

With the compass ruler you can physically measure the size of different underwater objects as you explore the oceans.

For use with FIFISH E-GO

navigation

U-QPS (underwater quick positioning system)

U-QPS underwater quick positioning system provides the real-time FIFISH ROV location, POI recording, 3-dimensional diving path recording and one-kick to return POI.

For use with FIFISH E-GO

manipulator tools

2 finger Robotic arm module

Optional compact 156mm short arm design for stable operation and precise grasp with clamp lock function. With a clamping and towing force of 100N (around 10kg) the full functioning robotic arm can easily drag, drop, tow and salvage underwater objects.

Aluminium alloy arm body, 316 stainless teel, high reliable sealing connector.

For use with FIFISH E-GO

retrieval hook

Optional rugged hook with powerful clamp and lock function that withstands the weight and pulls underwater objects up to 200kg.

For use with FIFISH E-GO

underwater dozer

Optional Underwater Dozer specially designed for aquaculture operations to push and move deceased/sick fish and other elements out of the fish farming spaces.

For use with FIFISH E-GO

fishing net

Optional Fishing Net designed for environmental fishing and marine education in mind. Provides the ability to catch and hold onto fish across different types of waters without threat or damage.

For use with FIFISH E-GO

sampling tools

water sampler

Optional Water Sampler to collect various types of water in different underwater environments for your specific needs. 100ml & 500ml available.

For use with FIFISH E-GO

mud sampler

Optional Mud Sampler to retrieve and sample a wide range of underwater sediments on the seabed.

For use with FIFISH E-GO

dissolved oxygen sensor

Optional Oxygen Sampler to monitor and record the level of dissolved oxygen in water contents.

For use with FIFISH E-GO

salinity sensor

Optional Salinity Sensor to measure the value of dissolved salt in the water.

For use with FIFISH E-GO

turbidity sensor

Optional Turbidity Sensor to measure the amount of light that is scattered by the suspended solids in the water.

For use with FIFISH E-GO

ph sensor

Optional pH Sensor to measure alkalinity and acidity levels in the water.

For use with FIFISH E-GO

other Accessories & spares

waterproof backpack bag

Specially designed, lightweight, and portable. QYSEA’s underwater drone backpack is uniquely customised for the FIFISH ROV. The outer layer of the backpack is made out of a TPU double-sided waterproof material that effectively protects the tether spool and remote controller from rainfall and storms. In addition to its 35L storage capacity, the backpack’s comfortable decompression-carrying system delivers a high load-bearing and lightweight carrying experience.

For use with FIFISH E-GO

Sunhood for controller

Optional Sunhood to hold iPads and tablets. It features an adjustable clamp to achieve a range of viewing angles for an unobstructed operating experience.

For use with FIFISH E-GO

vr headset

Optional VR headset to be used with a compatible smartphone/tablet. Control your underwater drone’s direction and movements simply by turning your head.

For use with FIFISH E-GO
