FIFISH V6 EXPERT

FIFISH V6 EXPERT

High Performance & Multi-functional Underwater Productivity Tool

FIFISH V6 EXPERT is a professional-class underwater robot and multi-capable tool for enhancing your underwater missions and operations.

When equipped with an onshore power supply system the V6 EXPERT delivers optimal diving performance and operating time.

True 360° Omni Directional Movement, Free As You Go
FIFISH V6 EXPERT has 6 degrees of freedom.  Free like a fish, V6 EXPERT moves in all directions: 360° rotation, lateral and tilt. When moving in any direction, the Posture Lock can ensure the angle of the drone.
True 360° Omni Directional Movement, Free As You Go
 FIFISH V6 EXPERT has 6 degrees of freedom.  Free like a fish, V6 EXPERT moves in all directions: 360° rotation, lateral and tilt. When moving in any direction, the Posture Lock can ensure the angle of the drone.

6000 Lumen Lights
Featuring 2 x 3000 Lumen LED headlights with different levels of brightness the V6 EXPERT can also be used in low visibility or at night.

Micro SD Card,Fast Transfer & Storage
The SD card can be taken out of the V6 EXPERT for data exporting with ease. The ROV comes equipped with a 128GB card for ample space and storage of high-definition films and images.

  • Posture Lock
  • Depth Lock
  • 100m Cable (standard)
  • Secure and Fast Charging
  • Onshore Power Supply System (option)
  • Q-IF Multifunctional Extension Interface
  • DNG Format Support
  • 240 FPS Slo-Mo Filming

FIFISH V6 EXPERT is a professional-class underwater robot and multi-capable tool for enhancing your underwater missions and operations.

When equipped with an onshore power supply system the FIFISH V6 EXPERT delivers optimal diving performance and operating time.

True 360° Omni Directional Movement, Free As You Go
 FIFISH V6 EXPERT has 6 degrees of freedom.  Free like a fish, V6 EXPERT moves in all directions: 360° rotation, lateral and tilt. When moving in any direction, the Posture Lock can ensure the angle of the drone.

6000 Lumen Lights
Featuring 2 x 3000 Lumen LED headlights with different levels of brightness the V6 EXPERT can also be used in low visibility or at night.

Micro SD Card,Fast Transfer & Storage
The SD card can be taken out of the V6 EXPERT for data exporting with ease. The ROV comes equipped with a 128GB card for ample space and storage of high-definition films and images.

  • Posture Lock
  • Depth Lock
  • 100m Cable (standard)
  • Secure and Fast Charging
  • Onshore Power Supply System (option)
  • Q-IF Multifunctional Extension Interface
  • DNG Format Support
  • 240 FPS Slo-Mo Filming

Multi tool Extensions, unlimited possibilities

FIFISH V6 EXPERT’s interface Q-IF (QYSEA Interface) enables the efficient integration of a wide range of professional-level and industry-specific tools to tackle different scenarios and tasks. The most popular accessory is the Robotic arm as this enables the V6 PLUS to perform underwater retrieval as the robotic arm can grab objects and features a clamp lock function. With a clamping and towing force of 100N (around 10kg) the full functioning robotic arm can drag, drop, tow and salvage underwater objects.   A wide range of inspection, measurement, navigation and manipulator tools are available.

The FIFISH V6 EXPERT ROV is powered by 6 thrusters which provide incredible manoeuvrability, move sideways, forwards, backwards, up, down, roll, pan and tilt with exceptional stability whilst filming or taking single shot photographs with the Sony 4K UHD camera with 166o field of view down to a maximum depth of 100m.

Fully Optimised Camera System
The V6 EXPERT delivers 4K footage at 30 frames per second or can film at 1080p with an impressive resolution of 120fps. With an advanced motion stabilisation system the V6s also avoids blurred shots. The H.265 codec offers advanced compression, resulting in higher storage efficiency with greater detail.

Posture Lock
An interesting feature of the V6 is Posture Lock whereby the user can tilt the V6 to an angle e.g. 45degree then maintain that angle while moving in the desired direction, this can be especially useful when performing hull inspections, wreck inspection etc

Immersive VR Adventure
FIFISH V6 integrates VR smart technology that fully immerses the user into the underwater world. With the Head Tracking feature, put yourself into the drones first-person-view and control where you want to go simply by turning your head.

FIFISH V6 EXPERT SPECIFICATIONS

ROV

Dimensions:           383mm x 331mm x 143mm
Weight:                    4.6kg
Thrusters:               6 Thrusters (FIFISH Q-Motor Technology)
Manoeuvrability:    6 Degrees of Freedom
                                 Movement: left & right, up & down, forward & backward
                                 Rotation: 360° pitches, 360° rolls, 360° yaws
Posture LockTM:     Lock the ± 0.1° pitch or roll angle, in any direction
Hovering:                Keep the ROV suspending in ± 1cm
Speed:                     Maximum 3 knots
Depth Rating:         100m (328ft)
Temperature Range: -10°C to 60°C (14°F to 140°F)
Max Dive Time:       Up to 4hrs (depending on usage scenario)
Battery:                    Rated Capacity: 14,400mAH/156Wh
                                  1 hour quick charge (90% capacity)
                                  Charge Voltage: 12.6 V
                                  Li-ion Panasonic 21700

LIGHTS

Brightness:            6000 Lumen LED
CCT:                         5500 K (Correlated Colour Temperature)
Beam Angle:           120°
Levels:                    3 x Brightness Levels

CHARGER

ROV:                        Input: 100-240, 50/60Hz, 3.0 A Max
                                Output: 12.6V=10A
RC:                          Input 100-240, 50/60Hz, 0.5 A Max
                                Output: 5V = 3A

TETHER

Length:                    100m standard on spool
Breaking Force:      100 kgf

CAMERA

Sensor:                1/2.3” SONY CMOS
Pixels:                  12MP
ISO Range:           100 – 6400 in Auto/Manual
Lens:                     Field of View: 166 °
                               Aperture: f/2.5
                               Minimum Focus Distance: 0.4m
Shutter Speed:     5 -1/5000 Second
Burst Shooting:    1 / 3 / 5 / 7 / 10 Frames
White Balance:     2500K – 8000K
Exposure Comp.: -3.0EV to +3.0EV
Photo Resolution: 4:3: 4000 x 3000
Photo Format:       JPEG, DNG
Video Res:             4K UHD: 25/30 fps
                                1080P FHD: 25/30/50/60/100/120 fps
                                720P HD: 25/30/50/60/100/120/200/240 fps
Video Format:        MPEG4 – AVC/H.264, HEVC/H.265
Stabilisation:          EIS (Electronic Image Stabilisation)
Colour Encoding:  NTSC & PAL
Storage:                 Pluggable 128GB standard

CONTROLLER

Wireless:                5GHz WiFi,11a,n, ac
Battery Life:           Up to 4 hours
SD Card Support:  Micro-SD Card FAT32 & EXFAT Format
                                (to 128GB)
HDMI Output:         QYESA HDMI Output Box

Q-INTERFACE

Ports:                      1
Material:                Stainless steel 316
Voltage:                  9 – 12V

Product specifications & accessories are subject to change without notice
